    Shinova
    DM-130
    Biological Microscope
    Get Latest Price!
    1 Pieces
    Within 15 days against payment
    T/T, L/C, Paypal, Cash, Other
    40*26*49
    7.50
    Cat,Dog,Equine,Bovine
    Operating Room,Exam Room

Descriptions

Integrated digital microscope, resolution 1280×1024 (1.3M pixel)
USB2.0 output, plug and unplug freely
Support WINDOWS 2000/XP/VISTA system, Equipped with powerful applied software

Economic features, widely used in academic demonstration and health system


Specifications

Camera System:
Valid Pixel: 1280×1024 (1.3M pixel);
Output Mode: USB2.0;
Operation System: WINDOWS 2000/ XP/VISTA;
Software: ScopeImage 9.0;
Range of Viewing Field: >90%
Viewing Head: Seidentopf type Binocular Head, Inclined at 30°, Interpupilary Distance 48-75mm
Eyepiece: WF10×/18
Objective: Achromatic Objective 4×, 10×, 40×, 100×
Nosepiece: Backward Quadruple Nosepiece
Stage: Double Layers Mechanical Stage 132×142mm/ 75×40mm
Condenser: Abbe NA1.20 with Iris Diaphragm & Fliter
Focusing:    Coaxial Coarse & Fine Adjustment System, Range 24mm, Fine Division 0.004mm

Illumination: LED 3W, Brightness Adjustable


Configurations

Optional:
Eyepiece:    P16×/11;
Halogen Lamp 6V/ 20W, Brightness Adjustable;
Phase Contrast Kit;
Dark Field Attachment;

Polarization Attachment.
