Descriptions
VS-100 Multifunctional Veterinary Stethoscope delivers accurate auscultation of heart, lung, and Korotkoff sounds with acoustic integrity and clarity. An ergonomic design ensures comfort for the veterinarians and patient animals, even during extended use. VS-100 is a premier diagnostic instrument with unmatched performance, durability, and aesthetics for large, middle or small animals.
Applications
VS-100 is commonly used to auscultate animal vital sings in heart, lung, pulse, etc.
1. Animal cardiovascular: to listen to heart rate, heart sounds, heart murmurs, etc.
2. Animal respiratory: to listen to lung breath sounds, to distinguish lung lesions.
3. When measuring animal blood pressure, it is used to amplify the pulse sound for veterinary diagnosis.
4. When measuring animal fetal sound, it is used to auscultate the heart sound of the fetus during pregnancy.
Features
1. The diaphragm is made of high-quality polyester material, which is resistant to abrasion and has no distortion.
2. The auscultation head is made of high-quality zinc alloy material with excellent workmanship. The rotating shaft of turning 180 degrees can smoothly switch the auscultation surface flexibly. The earrings are adjustable and balanced.
3. The hose is soft and anti-aging.
4. The earplugs are made of imported high-elastic PVC synthetic material, which is comfortable to wear and does not leak sound. It is easy to disassemble and clean.
5. VS-100 multi-function veterinary stethoscope is a universal design, equipped with a double-sided flat hearing blocks and large, medium and small three-sized bell-shaped auscultation head, which can be combined into five different auscultation methods to meet the veterinary demands:
a) Large flat block: mainly auscultate heart low frequency sound, diastolic sound and high frequency heart murmur for large and medium animals.
b) Small flat block: mainly auscultate high-frequency heart sounds and murmurs for small animals.
c) Large bell-shaped head: to auscultate low, medium-frequency sounds and murmurs for large and medium animals.
d) Medium bell-shaped head: used for narrow areas such as ribs, to auscultate low, mid-frequency and murmurs.
e) Small bell-shaped head: to auscultate the low-frequency sounds and murmurs for small animals and newborn animals, and also to detect fetal heart sounds (heartbeats) for pregnant animals.
Specifications
Total length: 82cm (32 inches)
Tube length: 64cm (25 inches)
Large flat head diameter: 45mm
Small flat head diameter: 30mm
Large bell-shaped head diameter: 34mm
Medium bell-shaped head diameter: 25mm
Small bell-shaped head diameter: 20mm
Earrings: Two ears are opened 140mm, and the elastic value is 1.372-1.960N
Elastic earrings: Two ears open to 300mm, recover after 1 minute, deformation is not more than 10mm
Spring piece hardness: HR15N82.9-88.4
Frequency response curve: 100-500Hz, the attenuation is not more than 12 dB
500-1000Hz, the attenuation is not more than 20 dB.
